| Technology |
Zero bonding |
| Display size (Diagonal) |
55" |
65" |
75" |
86" |
98" |
110" |
| Aspect Ratio |
16:09 |
| Resolution |
3840*2160 60hz |
| Contrast Ratio |
Min 1200:1/5000:1(Depend on brand of OC) |
| Brightness |
350cd/m2 |
400cm/m2 |
450cm/m2 |
450cm/m2 |
500cm/m2 |
500cm/m2 |
| Display colour |
1.07B (10bit) |
| Input Ports (Minimum) |
HMDI*3(2 on back,1 on front),Full function type C*1(on front)Audio*1,RJ45*1 |
| Output Ports (Minimum) |
Touch USB*2(1 on front,1 on back),Line out*1,Optical*1,RJ45*1, HDMI Out ( Optional) |
| USB Ports (Minimum) |
USB2.0*1,USB3.0*4(2 on back, 2 on front), |
| Smart USB Port |
2 |
| Camera |
48MP along with 8 array mic ( Optional) |
| Communication port |
RS232 |
| Built In Speakers |
2*20W Speaker(standard)/Woofer bar(Optional) |
| Viewing Angle |
178° |
| Touch Technology |
1mm high accuracy IR touch |
| Touch Resolution |
32767*32767 |
| Touch Points |
40 points in windows/20 points in android |
| Writing Points |
20 points |
| Pen Recognition |
2mm |
| Split Screen |
Yes |
| Touch on/Off |
Yes |
| Touch Response Time |
8MS |
| OS Support/Embedded Player |
Yes |
| Stylus/Pen Holder |
2 magnetic pen |
| Networking |
10/100/1000M auto-identification and DHCP |
| Hardness, Anti Scratch, Anti-Glare |
Anti glare 4MM tempered glass |
| Software Features |
Magic pen,slip screen,annotation on any menu,save by QR code etc |
| Screen Mirroring, Wi reless content sharing |
Support Windows,Android,IOS,Chrome and touch back. |
| QR Code Scan |
Yes |
| Video Conferencing Interface |
Yes |
| Integrated Wireless and Bluetooth Module |
2.4+5G wifi,bluetooth5.0 |
| Accessories |
2*Magnetic pen,1*HDMI Cable(1.8),1*Touch USB Cable(1.8m),1*Power Cable(1.8M),1*Wall Mount |
| Power supply requirement |
110~240V/50~60Hz |
| Max Power consumption |
140W |
280W |
350W |
450W |
650W |
650W |
| In-built Android Hardware: |
CvteT982.81 /GK6780V100/RK3588 /MT9679 |
| CPU |
A55*4 /A55*8 |
| GPU |
G52*2 |
| Memory |
4GB(Standard)/8GB(Optional)/ 16 GB (Optional) |
| Storage |
32GB(Standard)/128GB(Optional) / 256GB(Optional) |
| Android Version |
13.0 / 14.0 |
| EDLA |
Optional |
